Preliminary Procedure

Preliminary Procedure

Remove the front bumper fascia opening cover. Refer to Front Bumper Fascia Opening Lower Cover Replacement

  1. Drivetrain and Front Suspension Frame Bolt Front

Caution: Refer to Fastener Caution in the Preface section.

Tighten 160 N·m (119 lb ft) Note: Do NOT reuse the old bolt.

  1. Front Bumper Energy Absorber Bracket Bolt

Tip

For removal only loosen the bolt.

Tighten

22 N·m (17 lb ft)

  1. Front Bumper Energy Absorber Bracket

Note:Secure the drivetrain and front suspension frame with hydraulic jack.

Front Bumper Impact Bar Replacement

The front bumper impact bar is welded on, and must be replaced at the factory welds to retain structure integrity. Refer to Front Bumper Impact Bar Replacement.
