Special Tools

EL-42059Cigar Lighter Socket Remover .

For equivalent regional tools. Refer to Special Tools

Removal Procedure

  1. Remove the auxiliary power outlet fuse from the fuse block.
  2. Remove the auxiliary power outlet fuse from the fuse block.
  3. Remove the receptacle:
    1. Look into the receptacle(2). There are two 3?€‰mm (0.11?€‰in) tab windows 12?€‰mm (0.47?€‰in) from the front of the receptacle. The EL-42059Cigar Lighter Socket Remover pushes the plastic latches from these tab windows and the receptacle can be pulled straight out.
    2. Place one side of the ?€?T?€? portion of theEL-42059Cigar Lighter Socket Remover into the tab window. TheEL-42059Cigar Lighter Socket Remover will not fit straight into the receptacle. Angle the slightly for insertion into the receptacle.
    3. Insert the other side of the ?€?T?€? into the opposite tab window.

      You must move theEL-42059Cigar Lighter Socket Remover handle toward horizontal to engage the other tab window.

    4. Use theEL-42059Cigar Lighter Socket Remover to pull the receptacle straight out.
Installation Procedure

  1. Route the connector through the retainer. Align the accessory power
  2. Route the connector through the retainer. Align the accessory power receptacle retainer to the slot in the opening.
  3. Install the retainer by pressing into place fully seated.
  4. Connect the electrical connector to the receptacle.
  5. Align the tabs on the receptacle to the slots in the retainer. Install the accessory power receptacle by pressing into place until fully seated.
  6. Install the accessory power receptacle fuse.
