Chevrolet Sonic Repair Manual: Intake Manifold Installation (1.8L LUW and LWE)

Chevrolet Sonic Repair Manual: Intake Manifold Installation (1.8L LUW and LWE)

  1. Clean the sealing surfaces.
  2. Install 4 NEW gaskets.

    Caution:

    Refer to Fastener Caution.

  3. Install the intake manifold (2) and the 7 intake manifold bolts (1) and tighten to 20 Y (15 lb ft)

    .



  4. Install the intake manifold brace (1).
  5. Install the 2 intake manifold brace bolts (2, 3) and tighten to 8 Y (71 lb in)

    .

Intake Manifold Removal
Note: Intake manifold bolts remain in intake manifold screw bores. Remove the 6 intake manifold bolts (1). Remove the intake manifold (1) along with th ...
