Specification

MDPS(Motor Driven Power Steering)
Steering gear

Rack & Pinion
Rack stroke
154 ± 1mm
Steering angle (Max.)
Inner
37.5° (+0.5° -1.5°)
Outer
31.4°

Tightening Torques

Tightening torque (kgf.m)

kgf.m
lb-ft
Wheel Hub nuts
88.3 107.9
9.0 11.0
65.1 79.6
Steering wheel lock nut
39.2 49.0
4.0 5.0
28.9 36.2
Steering column bolt. (to universal joint)
29.4 34.3
3.0 3.5
21.7 25.3
Steering column mounting nuts
12.7 17.7
1.3 1.8
9.4 13.0
Steering column mounting bolt
44.1 49.0
4.5 5.0
32.5 36.2
Bolt connecting universal joint bolt. (to pinion)
32.4 38.3
3.3 3.8
23.9 27.5
Tie rod end castle nut
23.5 33.3
2.4 3.4
17.4 24.6
Lower arm ball joint bolt & nut (to knuckle)
58.8 70.6
6.0 7.2
43.4 52.1
Steering gear box mounting bolt. (to sub frame)
88.3 107.9
9.0 11.0
65.1 79.6
Steering gear box heat protector.
