Kia Soul: Torque Converter Control Solenoid Valve (T/CON_VFS). Removal

Remove the under cover.
(Refer to Engine Mechanical System - "Engine Room Under Cover")
Remove the drain plug (A) and drain the ATF totally and then reinstall the drain plug.
Tightening torque :
33.3 43.1 N.m (3.4 4.4 kgf.m, 24.6 31.8 lb-ft)


Must be replaced with new gasket when installing the drain plug.
Remove the air cleaner assembly and air duct.
(Refer to Engine Mechanical System - "Air cleaner")
Remove the battery and battery tray.
(Refer to Engine Electrical System - "Battery")
Remove the wiring bracket (A).
Tightening torque :
9.8 11.8 N.m (1.0 1.2 kgf.m, 7.2 8.7 lb-ft)

Remove the air breather hose (A).
Remove the valve body cover (B).
Tightening torque:
11.8 13.7 N.m (1.2 1.4 kgf.m, 8.7 10.1 lb-ft)

Remove the solenoid valve connector (B) and the oil temperature sensor (A).

Remove the solenoid valve support bracket (B) and the valve body mounting bolt (A-1ea).
Tightening torque :
9.8 11.8 N.m (1.0 1.2 kgf.m, 7.2 8.7 lb-ft)

Remove the torque converter control solenoid valve (A).
