Pedal Height Inspection

1. Measure the distance from the center of the upper surface of the pedal pad to the floor covering and verify that it is as specified.


  • If not within the specification, replace the brake pedal.

  • Brake pedal height (reference value)
  • MZR 2.0, SKYACTIV-G 2.0, MZR 2.5: 125.0 mm {4.921 in}

  • MZR 2.3 DISI Turbo: 128.9 mm {5.075 in}

Pedal Play Inspection

1. Pump the pedal several times to release the vacuum in the power brake unit.

2. Gently depress the pedal by hand and measure the pedal play.

  • If not within the specification, inspect the wear of the joint pin. Replace it if there is any malfunction.

  • Brake pedal play
  • 4.0—8.4 mm {0.16—0.33 in}

NOTE:

  • If there is no malfunction in the joint pin, there is a possibility that the power brake unit has some malfunction. Verify that there are no malfunctions, and replace it if necessary.

Pedal-to-floor Clearance Inspection

1. Start the engine and depress the brake pedal with a force of147 N {15.0 kgf, 33.0 lbf}

.

2. Measure the distance from the center of the upper surface of the pedal pad to the floor covering and verify that it is as specified.


  • If it is less than the specification, inspect for air in the brake line.

  • Brake pedal-to-floor clearance (Brake pedal when depressed at 147 N {15.0 kgf, 33.0 lbf})
  • MZR 2.0, SKYACTIV-G 2.0, MZR 2.5: 83.5 mm {3.29 in} or more

  • MZR 2.3 DISI Turbo: 88.6 mm {3.49 in} or more
