Mazda 3 Service Manual: Clutch Fluid Leakage Inspection [C66 M R]

CAUTION:

  • Do not allow clutch fluid get on a painted surface. Clutch fluid contains properties which can dissolve the paint. If clutch fluid gets on a painted surface, wash it off with water immediately and wipe the area off completely.

1. Pump the clutch pedal a few times.

2. Inspect for the clutch fluid leakage at the points indicated in the figure.


NOTE:

  • If there is clutch fluid leakage from the piston in the clutch release cylinder, there is clutch fluid in the boot of clutch release cylinder.

  • If there is clutch fluid leakage, repair or replace the malfunctioning location.
