Mazda 3 Service Manual: Clutch Pedal Position (CPP) Switch Inspection Mzr 2.0, Mzr 2.5

Mazda 3 Service Manual: Clutch Pedal Position (CPP) Switch Inspection [Mzr 2.0, Mzr 2.5]

Continuity Inspection

1. Verify that the CPP switch is installed properly..

2. Remove the battery cover..

3. Disconnect the negative battery cable..

4. Disconnect the CPP switch connector..

5. Verify that the continuity between CPP switch terminals A and B when the clutch pedal is depressed and when it is released is according to the following table:


  • If not as verified, replace the CPP switch..
