Mazda 3 Service Manual: TCM Configuration [Fw6 A EL]

NOTE:

  • The TCM is built into the control valve body.

1. Verify TCM configuration implementation necessity for replacement parts.

Replacement part

Configuration necessity

Control valve body replacement

Necessary

Oil pressure switch replacement

Unnecessary

Automatic transaxle replacement

Unnecessary

ON/OFF solenoid replacement

Unnecessary

Coupler component replacement

Unnecessary


2. Connect the M-MDS (IDS) to the DLC-2.

3. After vehicle identification, the following can be selected from the IDS initialization screen.

  • “Module Programming”

4. Then, select the following from the screen menu.

  • “Programmable Module Installation”

  • “TCM”

5. Perform the configuration following the instructions on the screen.

6. Verify that no DTCs are stored.

NOTE:

  • If any DTC (U code) is output, the system is normal.

7. Delete the U code and verify that no DTC is output.
