Nissan Rogue Service Manual: C1142 press sensor

Nissan Rogue Service Manual: C1142 press sensor

DTC Logic

DTC DETECTION LOGIC

DTC Display Item Malfunction detected condition Possible causes
C1142 PRESS SEN CIRCUIT When a malfunction is detected in master cylinder pressure sensor
  • Stop lamp switch system
  •  ABS actuator and electric unit (control unit)
  •  Brake system

DTC CONFIRMATION PROCEDURE

1.CHECK SELF-DIAGNOSTIC RESULT

With CONSULT.

  1.  Turn ignition switch OFF to ON.
  2.  Perform self-diagnostic result.

Is DTC C1142 detected? YES >> Proceed to diagnosis procedure. Refer to BRC-94, "Diagnosis Procedure".

NO >> Inspection End.

Diagnosis Procedure

1.CHECK STOP LAMP SWITCH SYSTEM

Check stop lamp switch system. Refer to BR-7, "Inspection".

Is the inspection result normal? YES >> GO TO 2.

NO >> Repair or replace malfunctioning components.

2.CHECK BRAKE FLUID LEAKAGE

Check brake fluid leakage. Refer to BR-8, "Inspection".

Is the inspection result normal? YES >> GO TO 3.

NO >> Repair or replace malfunctioning components.

3.CHECK BRAKE PEDAL

Check brake pedal. Refer to BR-7, "Inspection".

Is the inspection result normal? YES >> GO TO 4.

NO >> Repair or replace malfunctioning components.

4.CHECK HYDRAULIC BOOSTER ASSEMBLY

Check hydraulic booster assembly. Refer to BR-10, "Inspection".

Is the inspection result normal? YES >> GO TO 5.

NO >> Repair or replace malfunctioning components.

5.CHECK SELF DIAGNOSTIC RESULT

With CONSULT.

  1.  Turn ignition switch OFF to ON.
  2.  Perform self-diagnostic result.
  3.  Erase DTCs.
  4.  Start engine and drive vehicle for a short period of time.
  5.  Turn ignition switch OFF to ON.
  6. Perform self-diagnostic result.

Is DTC C1142 detected? YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-136, "Removal and Installation".

NO >> Inspection End.
