Nissan Sentra Service Manual: Body component parts

Nissan Sentra Service Manual: Body component parts


  1. Moonroof panel assembly
  2. Roof panel assembly
  3. Front roof rail
  4. Roof rail
  5. Rear roof rail
  6. Moonroof frame assembly
  7. Hood assembly
  8. Front fender (RH, LH)
  9. Outer front door panel (RH, LH)
  10. Outer rear door panel (RH, LH)
  11. Front door assembly (RH, LH)
  12. Rear door assembly (RH, LH)
  13. Front body side outer (RH, LH)
  14. Rear body side outer (RH, LH)
  15. Rear wheel housing outer (RH, LH)
  16. Rear pillar reinforcement (RH, LH)
  17. Outer sill reinforcement (RH, LH)
  18. Front pillar reinforcement (RH, LH)
  19. Front pillar reinforcement (RH, LH)
  20. Center pillar reinforcement (RH, LH)
  21. Roof side rail reinforcement (RH, LH)
  22. Center pillar inner (RH, LH)
  23. Roof inner side rail (RH, LH)
  24. Rear wheel housing inner (RH, LH)
  25. Rear inner sill extension (RH, LH)
  26. Rear panel assembly (RH, LH)
  27. Rear parcel shelf extension (RH, LH)
  28. Rear panel
  29. Trunk lid assembly
