Fender protector

Fender protector : exploded view


  1. Front fender protector
  2. Front wind deflector
  1. U nut
  2. Rivet
  3. Grommet

Fender protector : removal and installation - front fender protectorFront


Fender protector : removal and installation - front fender protector

REMOVAL

  1. Remove front wheel and tire. Refer to WT-47, "Adjustment".
  2. Remove front fender protector screws and clips
  3. Remove front fender protector from wheel house.

INSTALLATION

Installation is in the reverse order of removal.

Fender protector : exploded view


  1. Rear wheel opening molding
  2. Rear fender protector
  1. Clip
  2. U-clip

Fender protector : removal and installation - rear fender protectorFront


Fender protector : removal and installation - rear fender protector

REMOVAL

  1. Release the rear wheel opening molding pawls and remove rear wheel opening molding.
  2. Remove the rear fender protector clips, bolt and the rear fender protector.

INSTALLATION

Installation is in the reverse order of removal.

Rear wind deflector

Rear wind deflector : exploded view


  1. Rear wind deflector

Rear wind deflector : removal and installationFront


Rear wind deflector : removal and installation

REMOVAL

  1. Remove the rear wind deflector screws and the rear wind deflector.

INSTALLATION

Installation is in the reverse order of removal.
