Console

CONSOLE : Removal and Installation

REMOVAL

  1. Remove the shift selector finisher. Refer to IP-17, "Removal and Installation".
  2. Remove the inside key antenna (console) screws (A) and inside key antenna (console) (1).

INSTALLATION


INSTALLATION

Installation is in the reverse order of removal.

Luggage room

Luggage room : removal and installation

REMOVAL

  1. Disconnect the harness connector (A) from the inside key antenna (luggage room) (1).
  2. Remove the inside key antenna (luggage room) clips (B), and remove.

INSTALLATION


INSTALLATION

Installation is in the reverse order of removal.

Outside key antenna

Driver side

Driver side : removal and installation

The driver side outside key antenna and driver side outside handle are serviced as an assembly. Refer to DLK-173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle".

Passenger side

PASSENGER SIDE : Removal and Installation

The passenger side outside key antenna and passenger side outside handle are serviced as an assembly.

Refer to DLK-173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle".

Installation is in the reverse order of removal.

Rear bumper

Rear bumper : removal and installation

REMOVAL

  1. Remove rear bumper fascia. Refer to EXT-20, "Removal and Installation".
  2. Disconnect the harness connector (B) from the rear bumper key antenna (1).
  3. Remove the nuts (A) that retain the rear bumper key antenna (1) to the body.

INSTALLATION


INSTALLATION

Installation is in the reverse order of removal.

Door request switch

Driver side

Driver side : removal and installation

The driver side door request switch and driver side outside handle are serviced as an assembly. Refer to DLK- 173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle".

Passenger side

PASSENGER SIDE : Removal and Installation

The passenger side door request switch and passenger side outside handle are serviced as an assembly.

Refer to DLK-173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle".

Trunk lid finisher

Trunk lid finisher : removal and installation

REMOVAL

  1. Remove the license lamp finisher. Refer to EXT-44, "Removal and Installation".
  2. Release the pawls and remove the trunk lid request switch (1).

: Pawl


INSTALLATION


INSTALLATION

Installation is in the reverse order of removal.

Intelligent key warning buzzer

Removal and installation

REMOVAL

NOTE:

The Intelligent Key warning buzzer is located in the front passenger side area of the engine compartment, near the washer tank.

  1. Remove the washer tank inlet. Refer to WW-51, "Exploded View".
  2. Remove the nut (B) and the Intelligent Key warning buzzer (1).
  3. Disconnect the harness connector (A) from the Intelligent Key warning buzzer (1) and remove.

INSTALLATION


INSTALLATION

Installation is in the reverse order of removal.

Remote keyless entry receiver

Removal and installation

REMOVAL

  1. Remove glove box assembly. Refer to IP-22, "Removal and Installation".
  2. Disconnect the harness connector from the remote keyless entry receiver.
  3. Remove the screw and remote keyless entry receiver.

INSTALLATION

Installation is in the reverse order or removal.

Intelligent key battery

Removal and installation

  1. Release the lock knob on the back of the Intelligent Key and remove the key.
  2. Insert a suitable tool (A) wrapped with a cloth into the slit of the corner and rotate it to separate the upper part from the lower part.

CAUTION:

  • Do not insert a tool into the notches of the Intelligent Key to pry it open, as this may damage the circuit board.
  • Do not use excessive force when opening the Intelligent Key, as this may result in damage to the internal components.
  • Do not touch the circuit board or battery terminal.
  • The key fob is water-resistant. However, if it does get wet, immediately wipe it dry.


  1. Replace the battery with a new one.

Battery replacement :Coin-type lithium battery (CR2032)

  1. Align the tips of the upper and lower parts, and then push them together until unit is securely closed.

CAUTION:

  • When replacing battery, keep dirt, grease, and other foreign materials off the electrode contact area.
  • After replacing the battery, check that all Intelligent Key functions work normally.

Trunk lid opener switch


Trunk lid opener switch

Removal and installation

REMOVAL

  1. Remove the instrument lower panel LH. Refer to IP-21, "Removal and Installation".
  2. Remove to the instrument finisher D (1).
  3. Remove the screws (A) that retain the switch carrier to the instrument finisher (D).


  1. Release upper tab and lower tab (B) using a suitable tool (C), then remove the trunk lid opener switch from the upper switch carrier.

INSTALLATION


INSTALLATION

Installation is in the reverse order of removal.

Trunk lid
Trunk lid assembly Trunk lid assembly : exploded view Trunk lid hinge LH/RH Torsion bar LH/RH Torsion bar clips Trunk lid finisher (if equipped) Emergency release handle Emergency rel ...
