Passenger compartment area

Passenger compartment area

1) Lower anchorages for child restraint system (page 1-33)


1) Lower anchorages for child restraint system (page 1-33) 2) Seatbelt (page 1-12)
3) Center console (page 6-6) 4) Front seat (page 1-2) 5) Rear seat (page 1-7)

1) Top tether anchorages (page 1-36)


1) Top tether anchorages (page 1-36) 2) Cargo area light (page 6-3) 3) Rear center seatbelt (page 1-18) 4) Cargo area cover (page 6-15)

1) Shift lever (MT) (page 7-16)/Select lever (AT and CVT) (page 7-19)


1) Shift lever (MT) (page 7-16)/Select lever (AT and CVT) (page 7-19) 2) Climate control (page 4-1) 3) Audio (page 5-1)
4) Navigation system (Refer to the Owner’s Manual supplement for the navigation system)
5) Multi function display (page 3-25) 6) Glove box (page 6-6)
7) Cup holder (page 6-8)
