Toyota Corolla Repair Manual: Side mudguard sub–assy lh

Toyota Corolla Repair Manual: Side mudguard sub–assy lh

Replacement

Hint

: use the same procedures for the rh side and lh side.

1. Remove side mudguard sub–assy lh

  1. Using a clip remover, remove the 8 retainers and 9 clips.
  2.  using a moulding remover, remove the mudguard.

2. Install side mudguard sub–assy lh

  1. Install the mudguard with 9 new clips.
  2.  install the 8 retainers to the mudguard.
