  1. Fold the seatback while pulling the lever. Return the seatback and secure it at the 1st lock position (most upright position).

    Move the seat as far back as possible.

    If your child restraint system interferes with a head restraint and cannot be installed properly, install the child restraint system after removing the head restraint.

  2. Widen the gap between the seat cushion and seatback slightly.
  • Type a

Toyota Highlander. Installation with latch system


  1. Latch the hooks of the lower straps onto the latch anchors.

    If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.

    For owners in canada: the symbol on a child restraint system indicates the presence of a lower connector system.

Toyota Highlander. Installation with latch system


  • Type b
  1. Latch the buckles onto the latch anchors.

    If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.

    For owners in canada: the symbol on a child restraint system indicates the presence of a lower connector system.

Toyota Highlander. Installation with latch system


Installing child restraints
Follow the child restraint system manufacturer´┐Żs instructions. Firmly secure child restraints to the seats using the latch anchors or a seat belt. Attach the top tether strap when installing a ch ...
