REPLACEMENT

HINT: COMPONENTS: See page 27-2 .

1. REMOVE REAR WHEEL

2. REMOVE REAR STABILIZER LINK ASSY LH

REMOVE REAR STABILIZER LINK ASSY LH


(a) Remove the 2 nuts and stabilizer link.

HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.

3. REMOVE REAR STABILIZER LINK ASSY RH

HINT: Remove the RH side using the same procedures as for the LH side.

4. INSPECT REAR STABILIZER LINK ASSY LH

INSPECT REAR STABILIZER LINK ASSY LH


(a) As shown in the illustration, flip the ball joint stud back and forth 5 times.

(b) Using a torque wrench and nut, turn the ball joint continuously at a rate of 3 to 5 seconds per turn and take the torque reading on the 5th turn.

Turning torque: 1.0 N*m (10 kgf*cm, 9 in.*lbf) or less

If the value is not within the specification, replace the rear stabilizer link assy with a new one.

NOTICE:

  • Check that neither unusual drag nor rattle occurs during the rotation.
  • Check that neither cracks nor grease leakage exists on the dust cover.

5. REMOVE REAR STABILIZER BAR BRACKET NO.1

REMOVE REAR STABILIZER BAR BRACKET NO.1


(a) Remove the 2 bolts and stabilizer bar bracket.

6. REMOVE STABILIZER BAR REAR

(a) Remove the stabilizer bar and 2 stabilizer bush.

7. INSTALL STABILIZER BAR REAR

INSTALL STABILIZER BAR REAR


(a) Install the stabilizer bush to the outer side of the stopper ring on the stabilizer bar.

(b) Install the stabilizer bar.

8. INSTALL REAR STABILIZER BAR BRACKET NO.1

INSTALL REAR STABILIZER BAR BRACKET NO.1


(a) Install the stabilizer bar bracket with the 2 bolts.

Torque: 19 NVm (194 kgfVcm, 14 ftVlbf)

9. INSTALL REAR STABILIZER LINK ASSY LH

INSTALL REAR STABILIZER LINK ASSY LH


(a) Install the stabilizer link with the 2 nuts.

Torque: 39 NVm (400 kgfVcm, 29 ftVlbf)

HINT: If the ball joint turns together with the nut, use a hexagon wrench (5 mm) to hold the stud.

10. INSTALL REAR STABILIZER LINK ASSY RH

HINT: Install the RH side using the same procedures as for the LH side.

11. INSTALL REAR WHEEL

Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)

12.
