To enter the “phone” mode, press the off-hook switch.

Making a phone call

  • Dialing by inputting a name
  • Speed dialing
  • Dialing by entering the number
  • Dialing from call histories

Receiving a phone call

  • Answering the phone
  • Refusing the call

Operations during a call

  • Transferring a call
  • Muting your voice
  • Inputting digits
  • Setting call volume

Adjusting the ring tone volume when receiving a call

Dialing by selecting a name

  1. Select “phonebook” using the “tune•scroll” knob.
  2. Select the desired name using the knob and press the off-hook switch.

By pressing
 (add s. Dial) and one of the speed dial buttons (from [1]
to [5])
while the desired name is selected, it can be registered as a speed dial.

Press (a-z)
to display the registered names in alphabetical order of the initial.

Speed dialing

  1. Select “speed dials” using the “tune•scroll” knob.
  2. Press the desired preset button (from  [1] to
    [5]) and
    press the off-hook switch.

To delete a registered speed dial, after selecting the desired preset button (from
[1] to [5])
press (delete)
and then press (yes).


To overwrite a speed dial, after selecting the desired preset button (from [1]
to[5])
press (yes).


Dialing by entering the number

  1. Select “dial by number” using the “tune•scroll” knob.
  2. Enter the phone number and press the off-hook switch.

Dialing from call histories

  1. Select “all calls”, “missed calls”, “incoming calls” or “outgoing calls” using the “tune•scroll” knob.
  2. Select a desired number using the knob and press the off-hook switch.

The following operations can be performed:

  • Registering a number as a speed dial

Press (add
s. Dial) and then press the desired preset button (from [1]
to [5]).


  • Deleting the selected number

Press
(delete) and press
 (yes).

When receiving a phone call

Answering the phone

Press the off-hook switch.

Refusing the call

Press the on-hook switch.

Receiving a call when on another call

Press the off-hook switch.

Pressing the off-hook switch again returns you to the previous call.

Operations during a call

Transferring a call

A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the following methods:

  1. Operate the cellular phone.

    Refer to the manual that comes with the cellular phone for the operation of the phone.

  2. Press the (hndset).*

*: This operation can be performed only when transferring a call from the cellular phone to the system during a call.

  • Muting your voice

Press
(mute).

  • Inputting digits

Press (0-9)
and use the “tune•scroll” knob to input the desired digits.

  • To send the input digits press
    (send).
  • When finished, press(exit) to return to the previous screen.

  • Setting call volume

To decrease the volume: turn the “pwr•vol” knob counterclockwise.

To increase the volume: turn the “pwr•vol” knob clockwise.

Adjusting the ring tone volume when receiving a call

To decrease the volume: turn the “pwr•vol” knob counterclockwise.

To increase the volume: turn the “pwr•vol” knob clockwise.

When talking on the phone

  • Do not talk simultaneously with the other party.
  • Keep the volume of the received voice down. Otherwise, voice echo will increase.

Automatic volume adjustment

When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less.

Phone call system functions

Depending on the cellular phone, certain functions may not be available.

Situations where the system may not recognize your voice

  • When driving on a rough road
  • When driving at high speeds
  • When air is blowing out of the vents onto the microphone
  • When the air conditioning fan emits a loud noise
