Toyota RAV4 Service Manual: Removal (2005/11-2006/01)

  1. Disconnect cable from negative battery terminal

Caution:

Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.

  1. Remove roof headlining assembly
  1. Remove the roof headlining (see page ir-26).
  1. Remove sliding roof side garnish lh

Toyota RAV4. Remove sliding roof side garnish lh


  1. Using a screwdriver, detach the claws and remove the garnish.

Hint:

Tape the screwdriver tip before use.

  1. Remove sliding roof side garnish rh

Hint:

Use the same procedures described for the lh side.

  1. Remove sliding roof glass sub-assembly

Toyota RAV4. Remove sliding roof glass sub-assembly


  1. Using a t25 "torx" driver, remove the 4 screws and glass.
  2. Pull the glass upward to remove it.
  1. Remove sliding roof weatherstrip
  2. Disconnect sliding roof drain hose
  1. Disconnect the 4 drain hoses.
  1. Remove sliding roof housing assembly

Toyota RAV4. Remove sliding roof housing assembly


  1. Remove the 4 bolts, 8 nuts and housing.

Notice:

Be careful not to damage the curtain shield airbag when removing the housing.
