Description

Refer to the description of "slip indicator light remains on" (see page bc-152).

Wiring diagram

Refer to the slip indicator light circuit (see page bc-152).

Inspection procedure

Notice:

When replacing the abs and traction actuator, perform the zero point calibration (see page bc- 24).

  1. Check can communication system
  1. Check if the can communication system dtc is output (see page ca-34).

Result



  1. Perform active test by intelligent tester (slip indicator light)
  1. Using the intelligent tester's active test, generate a control command, and then check that the slip indicator light operates.

Toyota RAV4. Perform active test by intelligent tester (slip indicator light)


Ok: the slip indicator light turns on and off.



Replace abs and traction actuator assembly

  1. Check combination meter
  1. Inspect the combination meter (see page me-15).
