Description

The srs is equipped with a voltage-increase circuit (dc-dc converter) in the center airbag sensor in case the source voltage drops.

When the source voltage drops, the voltage-increase circuit (dc-dc converter) functions to increase the voltage of the srs to a normal working level.

A malfunction in this circuit is displayed differently from other codes, in the fact that no dtcs are recorded. With a normal system code present, the source voltage drop is indicated when the srs warning light comes on.

A malfunction in this circuit is not recorded in the center airbag sensor .

The srs warning light automatically goes off when the source voltage returns to normal.

Wiring diagram

Toyota RAV4. Source voltage drop


Inspection procedure

  1. Check wire harness (center airbag sensor assembly - battery)

Toyota RAV4. Check wire harness (center airbag sensor assembly - battery)


  1. Turn the ignition switch off.
  2. Disconnect the negative (-) terminal cable from the battery, and wait for at least 90 seconds.
  3. Disconnect the e45 connector from the center airbag sensor .
  4. Connect the negative (-) terminal cable to the battery, and wait for at least 2 seconds.
  5. Measure the voltage of the wire harness side connectors.

Standard voltage



  1. Check wire harness (center airbag sensor assembly - body ground)

Toyota RAV4. Check wire harness (center airbag sensor assembly - body ground)


  1. Measure the resistance of the wire harness side connectors.

Standard resistance



  1. Check wire harness (center airbag sensor assembly - body ground)

Toyota RAV4. Check wire harness (center airbag sensor assembly - body ground)


  1. Measure the resistance of the wire harness side connectors.

Standard resistance



  1. Check srs warning light
  1. Turn the ignition switch off.
  2. Disconnect the negative (-) terminal cable from the battery, and wait for at least 90 seconds.
  3. Connect the e45 center airbag sensor connector.
  4. Connect the negative (-) terminal cable to the battery, and wait for at least 2 seconds.
  5. Turn the ignition switch on, and wait for at least 6 seconds.
  6. Operate all components of the electrical system (defogger, wiper, headlight, heater, blower, etc.) And check that the srs warning light does not come on.

Ok: srs warning light does not come on.
