Toyota Sienna Service Manual: Disc cannot be Played/ No Playable Files/ Copyright Protection Error
DTC 44-7D Disc cannot be Played
DTC 44-7E No Playable Files
DTC 44-7F Copyright Protection Error
DTC Detecting Condition
|44-7F||copy-protected file, which cannot be played, is used.|
HINT: After the inspection is completed, clear the DTCs.
1 CHANGE DISC
- Insert a disc with a playable file and check if the disc can be played correctly.
HINT: For details on playable files and discs, refer to the Owner's Manual.
OK: The disc can be played correctly.
