Toyota Sienna Service Manual: GPS Antenna Error/ GPS Antenna Power Source Error

DTC 58-40 GPS Antenna Error

DTC 58-41 GPS Antenna Power Source Error

DTC 80-40 GPS Antenna Error

DTC 80-41 GPS Antenna Power Source Error

DESCRIPTION

DTC No.

DTC Detection Condition

Trouble Area

58-40 GPS antenna error
  • Wire harness
  •  GPS antenna
  •  Radio and navigation assembly
58-41 Error of the power source to the GPS antenna
80-40 GPS antenna error
80-40 Error of the power source to the GPS antenna

INSPECTION PROCEDURE

HINT: After the inspection is completed, clear the DTCs.

1 CHECK HARNESS AND CONNECTOR (GPS ANTENNA - RADIO AND NAVIGATION ASSEMBLY)

  1. Check that the GPS antenna cord is securely connected to the radio and navigation assembly connector.

OK: The cord is securely connected.

2 REPLACE GPS ANTENNA

  1. Replace the GPS antenna with a normal one and check if the same problem occurs again.
  1.  Clear the DTCs.
  2.  Recheck for DTCs and check if the same trouble occurs again.

OK: Same problem does not occur.
