(a) The general VIN input instructions using the intelligent tester are shown below: (b) The arrow buttons (UP, DOWN, RIGHT and LEFT) and numerical buttons (0 to 9) are used to input the VIN.

(c) Cursor Operation To move the cursor around the tester screen, press the RIGHT and LEFT buttons.

(d) Alphabetical Character Input

(1) Press the UP and DOWN buttons to select the desired alphabetical character.

(e) Numerical Character Input

(1) Press the numerical button corresponding to the number that you want to input.

HINT:

Numerical characters can be selected by using the UP and DOWN buttons.

(f) Correction

(1) When correcting the input character(s), put the cursor onto the character using the RIGHT and LEFT buttons.

(2) Select or input the correct character using the UP and DOWN buttons, or the numerical buttons.

(g) Finishing Input Operation

(1) Make sure that the input VIN matches the vehicle VIN after input.

(2) Press the ENTER button on the tester.

Registration
NOTICE:The Vehicle Identification Number (VIN) must be input into the replacement ECM. HINT: The VIN is a 17-digit alphanumeric vehicle identification number. The intelligent tes ...
