Toyota Sienna Service Manual: Rear wiper rubber
1. REMOVE REAR WIPER BLADE ASSEMBLY
- Remove the rear wiper arm head cap from the rear wiper arm.
- Raise the rear wiper blade to the position as shown in the illustration where the meshing of the claw is disengaged with the click sound.
NOTICE: Be careful not to break the claw.
- Pull the rear wiper blade straight from the wiper arm toward the left side of the vehicle.
NOTICE: Do not fold the rear wiper arm with the rear wiper blade being removed from it.
2. REMOVE REAR WIPER RUBBER
- Pull the end of the rubber protruded from the blade stopper as shown in the illustration.
NOTICE: Do not pull out the wiper rubber forcibly.
Otherwise, the backing plates are deformed or blade claw is damaged. HINT: Pushing the position close to the middle of the blade raises the rubber, making easier to pull the rubber out.
1. INSTALL REAR WIPER RUBBER
- Install the 2 wiper rubber backing plates to the rear wiper rubber.
NOTICE: Be sure to install the wiper rubber backing plates in the right direction.
