Toyota Sienna Service Manual: The Other Callers Voice cannot be Heard, is too Quiet, or Distorted

Toyota Sienna Service Manual: The Other Caller's Voice cannot be Heard, is too Quiet, or Distorted

INSPECTION PROCEDURE

1 CHECK CELLULAR PHONE

  1. Check if the voice on the other side can be heard using a cellular phone.

OK: Voice can be heard

2 CHECK NAVIGATION SYSTEM

  1. Check that navigation sound can be heard from the driver side speaker.

OK: Audio sound can be heard

3 CHECK SETTINGS

  1. Check if the volume level is set to low on the CALL screen.

OK: The level is not set low

CHECK SETTINGS

4 CHECK SETTINGS

 CHECK SETTINGS

  1. Enter the "Handsfree Voice Quality Set" mode.
  2.  Check if the Receive Voice Level is set to "0".

    HINT: The Receive Voice Level can be set to 11 different levels, -5 to +5, with a 3 dB difference.

  3.  Check if the Receive Voice Level is set to the minimum or maximum level.

HINT: When the Receive Voice Level is set to the minimum or maximum level, the sound may be distorted.

OK: The Receive Voice Level is set to "0".

PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE
