Components

COMPONENTS

ILLUSTRATION Installation

Installation

INSTALLATION

PROCEDURE

1. INSTALL NO. 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY

(a) Engage the clamp to install the No. 1 indoor electrical key antenna assembly.

(b) Connect the connector.

2. INSTALL FRONT CONSOLE BOX

(See pageRemoval)

Removal

REMOVAL

PROCEDURE

1. REMOVE FRONT CONSOLE BOX

(See page2. REMOVE NO. 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY2. REMOVE NO. 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY)

2. REMOVE NO. 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY

(a) Disconnect the connector.

(b) Using a clip remover, disengage the clamp to remove the No. 1 indoor electrical key antenna assembly.
