DESCRIPTION

These DTCs are stored when a malfunction occurs in the stereo component tuner assembly.

DTC No.

DTC Detection Condition

Trouble Area

B1552

Internal malfunction of the navigation ECU

Stereo component tuner assembly

B158A

Screen noise adjustment fails

B15BA

When either of the following conditions is met:

  • Internal IC malfunction
  • Tuner malfunction

CAUTION / NOTICE / HINT

NOTICE:

After replacing the stereo component tuner assembly of vehicles subscribed to pay-type satellite radio broadcasts, XM radio ID registration is necessary.

PROCEDURE

1.

CHECK DTC

(a) Clear the DTCs (See page(b) Recheck for DTCs and check that no DTCs are output.).

(b) Recheck for DTCs and check that no DTCs are output.

OK:

No DTCs are output.

OK

USE SIMULATION METHOD TO CHECK

NG

REPLACE STEREO COMPONENT TUNER ASSEMBLY
