Opening the fuel tank cap

Perform the following steps to open the fuel tank cap.

■ Before refueling the vehicle

Turn the engine switch off and ensure that all the doors and windows are closed.

■ Opening the fuel tank cap

Open the fuel filler door.

Open the fuel filler door.

Turn the fuel tank cap slowly to open.

Turn the fuel tank cap slowly to open.

Closing the fuel tank cap

When replacing the fuel tank cap, turn it until a clicking sound is heard.

When replacing the fuel tank cap, turn it until a clicking sound is heard.

After releasing your hand, the cap will turn slightly to the opposite direction.

■Fuel types

Use unleaded gasoline. (Octane Rating 87 [Research Octane Number 91] or higher)

■Fuel tank capacity

Approximately 21.1 gal. (80.0 L, 17.6 Imp.gal.)

CAUTION

■Refueling the vehicle

Observe the following precautions while refueling the vehicle.

Failure to do so, may result in death or serious injury.

●Touch the vehicle or some other metal surface to discharge any static electricity.

Sparks resulting from discharging static electricity may cause the fuel vapors to ignite.

●Always hold the grips on the fuel tank cap and turn it slowly to remove it.

A whooshing sound may be heard when the fuel tank cap is loosened.

Wait until the sound cannot be heard before fully removing the cap.

In hot weather, pressurized fuel may spray out of the filler neck and cause injury.

●Do not allow anyone that has not discharged static electricity from their bodies to come close to an open fuel tank.

CAUTION

■Refueling the vehicle

●Do not inhale vaporized fuel.

Fuel contains substances that are harmful if inhaled.

●Do not smoke while refueling the vehicle.

Doing so may cause the fuel to ignite and cause a fire.

●Do not return to the vehicle or touch any person or object that is statically charged.

This may cause static electricity to build up, resulting in a possible engine hazard.

■When replacing the fuel tank cap

Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.

NOTICE

■Refueling

Do not spill fuel during refueling.

Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle’s painted surface.

■To prevent damage to the fuel filler door

Do not apply excessive force.
